C01630C00610012-Amphenol Male Connector, C16-M Eco-mate Series, 6+PE

Contact Us

Description:

  • 6+PE Male receptacle with solder termination
  • Silver plated contacts
  • Comparable to 09-4219-00-07, CA6GS

Manufacturer: Amphenol

Manufacturer Part No.: C01630C00610012

IHL Part No.: C01630C00610012

  • Number of Contacts: 6+PE
  • Type: Solder
  • Backshell Colour: Black
  • Rated Voltage: 250 V
  • Rated Impulse Withstand Voltage: 4000 V
  • Current Carrying Capacity: 12 A/ + 55 °C
  • Insulation Resistance: ≥ 10(8) Ω
  • Contact Resistance: ≤ 5 mΩ
  • Climatic Category: 40 / 125 / 56
  • Operating Temperature: -40°C to +125°C
  • Degree of Protection: IP67
  • Insertion and Withdrawal Force: < 30 N
  • Mechanical Operation: > 500 Mating Cycles
  • Housing Material: PA 6.6 / PA 6
  • Dielectric Material: PA 6.6 / PA 6
  • Gasket Material: Neopren
  • Material Lace for Protective Cap: TPE
  • Contact Plating: Silver Plated
  • Termination Technique: Solder
  • Wire Gauge / AWG: Max. 2,5 mm² / AWG 14
  • Flammability: V0
  • Locking System: Round Thread
  • Voltage Rating: 250V
